Side scraper reclaimer is widely used in cement, building material, coal, power, metallurgy chemical and other industries, dealing with the preblending of the limestone, coal, iron ore and auxiliary raw material for cement plant. The equipment has the capacity of 100-2500t/h.

The side scraper reclaimer is applicable to the bulk material pile stacked in cone-shell method. When the equipment is started, the scraper carries out the reclaiming close to the pile surface, at the meantime, the travelling mechanism begin to walk until reach the limit position. Then the scraper boom falls by a certain angle, and begins to walk in the opposite direction until to the limit position on the other end. Such operation will be repeated in the reclaiming process.

· Overall pre-assembly

· Reliability due to the strict enforcement of design requirement and perfect process technology

· Sophisticated design tools, such as CAD, 3D and optimal design of steel structure

· Advancement. The equipment can be fully automated for stacking operations, thus being a highly automated product.

The equipment consists of scraper reclaiming system, hoist system, machine rack, restrained beam, swing end beam, rail system, guide chute, power cable reel, control cable reel and etc.
